Digital logic design tool and simulator

Logisim-evolution is educational software for designing and simulating digital logic circuits. Logisim-evolution is free, open-source, and cross-platform.

Project highlights:

  • easy to use circuit designer,
  • logic circuit simulations,
  • chronogram (to see the evolution of signals in your circuit),
  • electronic board integration (schematics can be simulated on real hardware),
  • VHDL components (components behavior can be specified in VHDL!),
  • TCL/TK console (interfaces between the circuit and the user),
  • huge library of components (LEDs, TTLs, switches, SoCs),
  • supports multiple languages,
  • and more!

Details for logisim-evolution

License
  • GPL-3.0

Last updated
  • 2 March 2023 - latest/stable
  • 25 September 2022 - latest/edge
